Description
**BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty applications. Because of the high-stress nature of their use, these engines are sold without any warranty, expressed, or implied.
Description:
- Horsepower and Torque: 610 Horsepower / 525 ft. lbs. Torque
- Cylinder Heads: Gen III Hemi Apache Aluminum Cylinder Heads
- Compression Ratio: 10.48:1
- Gen III Hemi Apache Aluminum Cylinder Heads
- BluePrint Engines Hydraulic Roller Cam
- BluePrint Engines Forged Crank
- BluePrint Engines Forged Pistons
Block:
- NEW “BGE” Hellcat / Apache Engine Block
- 1-Piece Rear Main Seal
- 4-Bolt Main
- 4.090″ Bore
Rotating Assembly:
- Forged Crank
- 4.050″ Stroke
- 6.125″ Connecting Rods
- Forged Pistons
- Internally Balanced Front and Rear
Cylinder Heads:
- Gen III Hemi Apache Aluminum Cylinder Heads
- 73cc Chamber
- 2.140″ Intake / 1.650″ Exhaust Valves
- Can Accept 6.1, 6.4 or 2009+ 5.7L Intake Manifolds
- Does Not Accept 2008 or Older 5.7L Intakes
- Not Tapped for Stock Hellcat Supercharger. Bolt Pattern Differs from N/A Intake
Cam Specs:
- Hydraulic Roller Cam
- .614 Intake / .614 Exhaust Lift
- 231 Intake / 255 Exhaust Duration
- @.050-115 Degree Lobe Separation
Also Includes:
- GEN III Hemi Compatible Coils – BPP68238603
- Spark Plugs – NGK 97408 / LZTR6AP11EG
- Mid Sump Swap Oil Pan
- Harmonic Balancer
- Timing Cover (Car)
- Valve Covers
- Water Pump
Notes:
- BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty applications. Because of the high-stress nature of their use, these engines are sold without any warranty, expressed, or implied.
- Features 2013+ 58X reluctor wheel
- Will work with 2009+ ECU as long as paired with 2013+ Crank Sensor.
- 2009+ crankshaft spacing
- 2009+ car timing cover
- VVT locked out
- MDS – eliminated
