Description
**BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty race applications. If this engine is used in a street application our normal 30 month, 50,000-mile warranty applies, if used in sanctioned racing no warranty, expressed, or implied.
Description:
- Horsepower & Torque: 1000 Horsepower / 800 ft. lbs. Torque
- Compression Ratio: 10.65:1
- Brodix SR20 CNC Ported Heads
- Solid Roller Cam
- Mahle Forged Pistons
- Callies Forged Steel Crank
Block:
- BluePrint Engines Cast Iron Block
- Manufactured and Machined in the USA!
- Tall Deck (Cylinder Deck is Approx .400 taller / Wider than OEM Block)
- 1-Piece Rear Main Seal
- 4-Bolt Main
- 4.600″ Bore
Rotating Assembly:
- Callies Forged Steel Crank
- 4.750″ Stroke
- 6.635″ Connecting Rods
- Mahle Forged Pistons
- Internally Balanced Front and Rear
Cylinder Heads:
- Brodix SR20 CNC Ported Heads
- 95cc Chamber
- 2.400″ Intake / 1.800″ Exhaust Valves
- 440 Intake Runner Volume (cc)
Cam Specs:
- Solid Roller Cam
- .874 Intake / .867 Exhaust Lift
- 293 Intake / 305 Exhaust Duration
- @.050-110 Degree Lobe Separation
Also Includes:
- Holley Sniper Stealth 4500
- BluePrint Engines Intake Manifold
- Moroso Aluminum Oil Pan
- MSD Pro Billet Distributor
- SFI Harmonic Balancer
- Spark Plug and Wires
- Timing Cover
Note:
- For racing or extended wide-open throttle use, race fuel (100+ octane) is required.
- BluePrint Motorsports engines are built for maximum performance and are intended for extreme duty applications. Because of the high-stress nature of their use, these engines are sold without any warranty, expressed, or implied.
- Oil Requirements: 20W50
