Himiway D5 Pro Zebra Edition All-Terrain Fat Tire E-Bike

Description

Himiway D5 Pro ST: The Premium All-Terrain Electric Fat Bike

• Conquer Any Landscape with Superior Traction & Suspension

• Built for Endurance: Long-Range Battery & Durable Design

Unleash your adventurous spirit with the Himiway D5 Pro, the premium all-terrain electric fat bike engineered to tackle the most challenging environments. Whether you’re navigating snowy paths, sandy beaches, rugged trails, or urban commutes, the Himiway D5 Pro delivers an unparalleled blend of power, comfort, and reliability. This fat tire electric bike is built for those who demand more from their e-bike.

More

·  Mid-Drive Power & Torque Sensor:

At the heart of the Himiway D5 Pro is a responsive 500W Bafang mid-drive motor. Unlike hub motors, this mid-drive electric bike provides a more natural riding feel, better weight distribution, and incredible climbing power. The integrated torque sensor intelligently amplifies your pedaling efforts, ensuring a smooth, intuitive, and efficient ride up to 25 MPH.”

·  Long-Range Battery:

Go further than ever before with the Himiway D5 Pro‘s high-capacity 48V 20Ah Samsung/LG lithium-ion battery (960Wh). This long-range electric bike offers an impressive 60-80 miles on a single charge with pedal assist, allowing you to explore vast landscapes without range anxiety. The integrated battery design enhances the bike’s sleek aesthetics and protects against elements.

·  All-Terrain Dominance:

Equipped with aggressive 26″x4.0″ Kenda fat tires, the Himiway D5 Pro offers superior grip and stability on virtually any surface. The front suspension fork with lockout and adjustment (100mm travel) absorbs shocks, providing a comfortable and controlled ride even on rough terrain. Paired with Tektro hydraulic disc brakes (180mm), you’ll have reliable stopping power in all conditions.

·  Durable & Feature-Rich:

Constructed with a robust 6061 aluminum frame that’s 2X thicker than conventional bikes, the Himiway D5 Pro boasts a 400 lb payload capacity, making it a heavy duty electric bike suitable for a wide range of riders and gear. The Shimano 9-speed gear system allows for versatile pedaling, while the LCD display with USB-C charger keeps your devices powered. This premium electric bike is designed for the long haul.

Why Adventure Riders Choose the D5 Pro Mountain eBike:

✅ 750W High-Torque Motor – Power through 30° inclines and loose terrain.
✅ 4” Fat Tires – Float over mud, snow, and sand like a tank with treads.
✅ 80-Mile Monster Range – 960Wh battery lasts for multi-day off-grid trips.
✅ Cargo Beast Mode – Rear rack + front basket haul 400 lbs of gear (or groceries).

Specs

Geometry

Recommended Height: 5’3″ ~ 6’5″

A – total length 78.7 B – handlebar height 47 C – handlebar length 28 D – wheelbase 49.2 E – wheel diameter 28.7 F – minimum seat height 20.9 G – maximum seat height 31.4 H – chain stay length 19

I – frame stack 24.6 J – frame reach 17.8 K – effective top tube length 24.4 L – head tube length 5.5 M – head angle 65° N – standover height ST 22.4/ SO 31.1

Specification

Frame	6061 Aluminum frame
Headset	Neco H156EM 28.6*44-56*30
Fork	TRAMA FAT34-PLS-26″ 100mm travel 15*135mm thru axle
Shock	Alloy front suspension fork with lockout and adjustment
Front wheel	Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 255/256L stainless (304M) | Hub: MB015-92 M9*12G*135*145W
Rear wheel	Rim: MD-147 26*4.0″*36H*12G A/V | Spoke: 12G 256/257L stainless (304M) | Hub: GSMB019R-190F-GM14
Tires	Kenda 26*4.0
Battery	Samsung/LG 48V 20Ah
Motor	500W mid-drive motor
Display	KD718-P LCD display with Type-c charger
Throttle	Thumb throttle
Sensors	Torque sensor丨shifting sensor speed sensor丨brake sensor
Crankset	Crankarm: Prowheel 170mm / Chain ring: 44T BCD104
Freewheel	Shimano CS-HG201-9 11-36T
Chain	KMC E9 EPT 124L
Groupset	Shimano altus M2000 9 speed
Front brake	Tektro HD-E3520 hydraulic brake
Rear brake	Tektro HD-E3520
Rotors	Tektro TR180-52 F:180mm R:180mm

Components

Stem	Zoom TDS-C269-8FOV 31.8*90mm
Handlebar	Promax HB-3188 22.2*31.8*700mm
Seatpost	Himiway Seatpost
Saddle	Himiway Saddle
Pedal	Aluminum pedal
Lights	48V LED light
Kickstand	Heavy-duty aluminum kickstand

Others

Range	60-80 miles
Controller	48V/22A
Charger	US standard 3.0 A Smart charger
Rider height	5’3″ ~ 6’5″
Weight	79 lb. (with battery)
Max. payload capacity	400 lb.



Included in Delivery D5
