Description
The design has been integrated and optimized to provide a cleaner and sleeker layout. The overall length is now at 58mm, 6mm shorter than the previous version. The smaller footprint provides for a spacious, easy assembly process. Supports a variety of application needs such as the “constant speed mode (forward and reverse)”, “normal mode (forward and reverse with brake)”, and “normal mode without constant speed function (Forward and Reverse).
The IP-67 waterproof system guarantees excellent water and dust protection. The whole power system is able to drive on a variety of surfaces, including mud, sand, ice, and snow without damaging the power unit. The ESC is equipped with 13 adjustable parameters for fine-tuning adjustments. New parameters such as “maximum braking force”, “speed fluency”, “start mode ( Punch)”, “throttle midpoint area”, and other practical parameters are included.
Specifications:
| Motor KV | 2300KV |
| Cont./Peak Current | 60A/200A |
| Input Voltage | 2-3S Lipo/6-9 Cell NiMH |
| BEC Output | Switch Mode:6V/7.4V，6A |
| Input wires | Red-14AWG-330mm*1 / Black-14AWG-330mm*1 |
| Input connector | XT60 (factory installed) |
| Programming Port | Independent programming interface(switch position |
| Size / Weight | 37mm x 58mm / 209g (w/ wires+plug) |
| Shaft dim | 3.175mm / 16mm |
| Motor Pole | 4 |
| Programming | LED programmer (Sold separately) |
Includes:
- 1x FOC motor w/ built-in ESC
- Factory-installed XT60 plug
- 1x Decal and Manual
- 1x Heatshrink kit, double-sided tape, and zip ties.
MPN: HWI30120402
